± 0.04% Accuracy
± 0.2% per 15 years Stability
90 ms Response Time
15,200 psia Maximum Over Pressure
Exida and TUV SIL 2/3 Certified
Local Parameter Setting (LPS)
± 0.04% Accuracy
± 0.2% per 15 years Stability
90 ms Response Time
10,800 psig Maximum Over Pressure
Exida and TUV SIL 2/3 Certified
Local Parameter Setting (LPS)
± 0.04% Accuracy (0.025% Accuracy optional)
± 0.1% per 15 years Stability
90 ms Response Time
Exida and TUV SIL 2/3 Certified
Local Parameter Setting (LPS)
± 0.075% Accuracy
± 0.2% per 15 years Stability
90 ms Response Time
Exida and TUV SIL 2/3 Certification
LPS (Local Parameter Setting)
± 0.075% Accuracy
± 0.1% Stability per 1 year
120 ms Response Time
Exida and TUV SIL2 / SIL3 Certified
LPS (Local Parameter Setting)
Signal Characterizer for the 4 to 20 mA output
(
Signal output: 4-20mA HART digital communication protocol
(
Power supply: DC24V
(
Ambient temperature: -25-80°C
(
Liquid temperature: 1-40-120°C
(
Process isolation diaphragm: stainless steel, Hastelloy, Monel, non-ferrous metals, etc.
(
Connection mode: threaded connection Filling liquid: silicone oil and inert liquid
Local Indicator
Advanced Diagnostics
Digital Performance
Signal Characterization
± 0.055% Accuracy (0.04% Accuracy optional)
± 0.1% Stability per 10 years
90 ms Response Time
Exida and TUV SIL 2/3 Certified
Local Parameter Setting (LPS)
Accuracy ± 0.1 %
Stability ± 0.2 % url/10 years
The response time is 90 milliseclic
TUV and EXIDA SIL2 / SIL3 certification
Maximum work pressure 3,600 PSI
Accuracy ± 0.075%
Stability ± 0.1% URL/1 year
Response time 120 ms
TUV and Exida SIL2 / SIL3 certification
10-stage signal curve characterization
Local Parameter Setting (LPS)
0.2% Accuracy
700 ms Response Time
External Zero Adjustment
One -way overvoltage characteristics are excellent
No bracket, install it directly
Used in routine, no three valve groups need
The impact of static pressure is ignored
